API Spec 7K Oil Rig Rotary Table ZP375 Rotary Table For Oil Drilling

API Spec 7K Oil Rig Rotary Table ZP375 Rotary Table For Oil Drilling

API Spec 7K Oil Rig Rotary Table

Oil Rig Rotary Table ZP375

API Spec 7K ZP375 Rotary Table

Place of Origin:

China

Brand Name:

XI'AN RIG

Certification:

API 7K

Model Number:

ZP375

Chat Now
Request A Quote
API Spec 7K Oil Rig Rotary Table ZP375 Rotary Table For Oil Drilling API Spec 7K Oil Rig Rotary Table ZP375 Rotary Table For Oil Drilling API Spec 7K Oil Rig Rotary Table ZP375 Rotary Table For Oil Drilling
Product Details
Type:
Rotary Table
Model:
ZP375
Standard:
API Spec 7K
Function:
Rotate Drilling Tools
Function 2:
Bears Pipe String Weight
Application:
Oil Drilling
Highlight:

API Spec 7K Oil Rig Rotary Table

,

Oil Rig Rotary Table ZP375

,

API Spec 7K ZP375 Rotary Table

Payment & Shipping Terms
Minimum Order Quantity
1 set
Delivery Time
in stock
Payment Terms
T/T, L/C
Supply Ability
10 set /month
RELATED PRODUCTS
Good price High-Efficiency SL160X And SL225X Air‑Tube Spinner for Oilfield Operations online

High-Efficiency SL160X And SL225X Air‑Tube Spinner for Oilfield Operations

Chat Now
Good price API Cu / CB Type Casing Bushing Master Rotary Table Bushing and Insert Bowls For Oilfield online

API Cu / CB Type Casing Bushing Master Rotary Table Bushing and Insert Bowls For Oilfield

Chat Now
Good price High Quality Premium XFK‑77Q(Y) Claw‑Type Spinner for Oilfield Equipment online

High Quality Premium XFK‑77Q(Y) Claw‑Type Spinner for Oilfield Equipment

Chat Now
Good price API 7K Rotary Table Master Bushing and Insert Bowl for Oilfield online

API 7K Rotary Table Master Bushing and Insert Bowl for Oilfield

Chat Now
CONTACT US
8618291452987
depart01@xianrig.com
Chat Now
Product Description



API Spec 7K  ZP 375 Rotary Tables



Product summary:

ZP series turntables are widely used in oil drilling to rotate drilling tools and bear the weight of the pipe string in the well. They are one of the important parts of the drilling rig. They are designed and manufactured according to API Spec 7K "Drilling Equipment Specification"

API Spec 7K Oil Rig Rotary Table ZP375 Rotary Table For Oil Drilling
The rotary table is one of important supporting equipment of petroleum drilling rig and workover rig. It is used for supporting the weight of tubular column in process of drilling well and workover operations.
API Spec 7K Oil Rig Rotary Table ZP375 Rotary Table For Oil Drilling
The rotary table is reducer which is driven by couple helical gear or conic gear. It consists of box body, rotating table, main bearing, vice bearing, gear ring, input shaft assembly, locked device, square-slips and box cover

Gear wheel and pinions are all made of alloy steel.
• According to needs, master bushing and kelly roller bushing can adopt square drive or pin drive.
• Pin drive type master bushing can put into API standard kelly or hex kelly roller bushing Long clips and short clips are applicable.
• Full lubrication and steady seal.
• Rotatry table is according with API Spec 7k standard.


ZP series turntables are widely used in oil drilling to rotate drilling tools and bear the weight of the pipe string in the well. They are one of the important parts of the drilling rig. They are designed and manufactured according to API Spec 7K "Drilling Equipment Specification".

Model number ZP375 ZP275 ZP205 ZP175
Maximum static load kN 5850 4500 3150 2250
US ton 650 500 350 250
Through hole diameter mm 952.5 698.5 520.7 444.5
in 371/2 271/2 201/2 171/2
Gear ratio 　 3.56 3.67 3.22 3.58
Distance from the center of the turntable to the center line of the inner row of teeth of the sprocket mm 1353 1353 1353 1118
in 531/4 531/4 531/4 44
Dimensions mm 2468×1810×718 2392×1670×685 2392×1475×668 1935×1280×585
in 97×71×28 94×66×27 90×58×26 76×50×23
Weight kg 8026 6203 5530 3888
lb 17694 13680 12190 8572
