Place of Origin:
China
Brand Name:
XI'AN RIG
Certification:
API
Model Number:
disc brake-350
Wellhead Special Operation Tools and Components (High-Frequency Consumables / Process Components for Workover)
1. Tubing Elevators and Sucker Rod Elevators
Lift and suspend tubing and sucker rods, featuring self-locking and anti-release designs and large load capacities — essential tools for running and pulling strings.
2. Safety Slips and Wellhead Slips
Set and support the string, bearing the string weight and preventing the string from falling or sliding into the well — core wellhead safety tools.
3. Hydraulic Tong, Manual Tong, and Torque Wrench (Spinning/Makeup Tong)
Responsible for making up, breaking out, and torque control of tubing and sucker rod connections, preventing thread damage, back-off, and thread disconnection.
4. Lifting Tools, Centralizers (Alignment Tools), and Guide Tools
Assist in string makeup, centralization, and thread alignment, improving operational efficiency and protecting the threads.
| Workover rig model | Working calipers (set) | Safety calipers (set) | Maximum Hook Load (kN) | Working brake torque (kN·m) | Safety braking torque (kN·m) |
|---|---|---|---|---|---|
| XJ250 | 2 | 1 | 675 | 61 | 28 |
| XJ350 | 2 | 1(2) | 900 | 61 | 28/56 |
